Accommodations

As you enter the cockpit area, you will find comfortable seating on both sides, and a sun-blocking custom hard bimini, and removable side curtains. The protected helm is well situated to the port side of the companionway which leads to the main cabin, where the accommodation spaces are attractively finished with varnished Alaska yellow cedar hull surfaces and wood trim throughout. The overhead and bulkheads are coated with polyurethane paint.

Entering the aft cabin through the aft crossbeam bulkhead, there is a navigation station on the port side equipped with a 50" x 25" varnished black walnut chart table with flat chart storage beneath. The electronics area is above the chart table. A wet gear locker is  also located on the Port side. Large windows to port and starboard provide excellent visibility and light. An aft double berth is located in the aft portion of the compartment. There is storage below and aft of the berth. Two electric fans are provided in the aft berth area.

Next on both port and starboard sides is the galley. The aft port portion of this section houses the head compartment. The head is fitted with a stainless steel sink, a vanity with laminate counter top and stowage under. A mirror and cabinet are provided over the sink. There is a manual marine head with "Y" valve for selectable discharge either overboard or to a 30 gallon holding tank. The holding tank is located in the aft portion of the port float, ensuring that no odor will reach the living area.

Next, through the forward crossbeam bulkhead is the salon/dinette area. Settees are fitted on each side of a varnished black walnut drop leaf table. The settees are 7' long and also function as single berths. Ample stowage is provided beneath the seats and the cabin sole.

Next, forward of the salon area is the master cabin fitted with a 7' long double berth with storage below, a large #10 hatch providing light and ventilation, (2) portlights, (2) reading lights, and fans.

The forepeak houses the shower area including an on-demand hot water system. The water-maker is also installed in this compartment

Galley Equipment

• Laminate counter top
• Flush mounted double sink
• Fresh and salt water supplied by Whale Gusher foot pumps
• Pressure water supplied by in-line pressure pump
• Multiple drawers, cabinets and storage bins beneath the counter areas
• Shipmate stainless steel 4-burner propane stove/oven/broiler
• 2 x 10 lb. aluminum propane storage bottles in ventilated locker with solenoid shutoff
• Well insulated super-efficient top-opening refrigerator with Adler Barbour 12 volt compressor and holding plate

Design and Construction

• Open wing design with (2) crossbeams
• Low aspect keel on main hull
• Balanced hydrofoil section spade rudder operated by Edson pull-pull cable steering system with stainless steel wheel
• Sterling paint on hull and topsides

• Hulls and decks are vacuum bagged triple diagonal Alaska Yellow Cedar using WEST System® epoxy resin with glass/epoxy exterior skin
• Crossbeams are epoxy laminated Douglas Fir and marine plywood
• Sterling® polyurethane exterior finish with contrasting boot top.
• Epoxy/glass composite rudder blade with solid marine grade stainless steel stock turning in low friction bushings
• 3 x coats Micron 66 antifouling paint.

Sails and Rig

• Freestanding ketch rig provides effortless tacking and superb offshore reliability
• Tapered hollow wood/carbon fiber epoxy masts

• Custom Lazy Jacks
• Innovative sleeve luff sails are efficient and allow conventional slab reefing
• Custom gooseneck fittings allow the sails to be luffed on any point of sail to reef or lower sails

• Mainsail (450 sq ft) by Haarstick Sails, 2008, Dacron cloth. 3 x reef points, fiberglass battens, rugged construction details, sleeve luff
• Mizzen (450 sq ft) by Haarstick Sails 2008 Dacron cloth. 3 x reef points, fiberglass battens, rugged construction details, sleeve luff
• Mizzen staysail (500 sq ft)
• Mainsail and mizzen covers in Sunbrella fabric 2014
• New main halyards 2015

Deck and Hull Equipment

• (2) Lewmar Ocean Series # 43 CST (chrome self-tailing) main sheet and mizzen sheet winches
• Lewmar #30 CST dedicated vang/preventer winch
• (1) Lewmar #40 CST halyard winches
• New Lewmar 46 EST electric winch 2014
• Custom Atlantic tower arch amidships
• Dyneema netting -all trampolines 2011
• Custom stainless steel bow pulpit
• (2) 12" mooring cleats
• (6) 10" dock cleats
• Bulkhead mounted Edson wheel with wheel brake, adjacent engine controls, compass and sailing instruments
• (4) Lewmar deck hatches over the main hull, with screens
• Custom deck hatch in each float to access stowage space
• Opening port in head
• (2) opening ports in shower
• Aluminun dual anchor rollers
• Self-bailing deck lockers behind forward crossbeam for anchors and rode.
• (2) 35 lb. CQR Plow anchors, each with 20' chain and 150' x 3/4" nylon rode.
• (1) 40 lb. Danforth hi-tensile anchor
• (1) Fortress FX55 storm anchor
• 200' x 3/4" spare anchor rode
• (4) dock lines, 30' x 1/2" braided rope with spliced ends,
• (5) Par 10" x 24" fenders
• Custom Bimini with removable clear side curtains
• Shade cloths (80% shade) for sides and back of Bimini for use at anchor
• Removable cockpit dining table
• Deck awning
• Stainless steel swim ladder
• Dinghy chocks, power winch lift

Machinery

• In-line transmission with 2:1 reduction
• Vibration damping engine mounts
• PSS dripless shaft seal,
• Vibration damping Aquadrive® thrust bearing between transmission and stuffing box.
• Shaft coupling.
• Instrument panel with tachometer and engine monitoring gauges and alarms
• Primary and secondary fuel filters
• Raw water strainer
• Fiberglass "Aqualift" exhaust silencer
• Sound insulated engine room floor
• Single lever engine controls mounted at helm station
• Gori bronze 2 blade, folding propeller
• Spare 2 blade fixed prop
• Aquamet 22 propeller shaft
• PUR 80 12 volt water-maker, 3 GPH (requires new membrane)
• Wallas series 3000 forced hot air externally vented diesel heater

Electrical System

• 12 volt electrical panel with volt and amp meters and (8) circuit breakers
• Battery selector switch
• (2) 4D wet-cell house batteries 2014, (1) group 27 AGM Separated start battery
• (6) 80 watt solar panels (Total 480 Watts with Xantrex 35 amp auto control power regulator
• Heart Interface 750 watt Freedom 7 continuous output inverter/charger
• Aquasignal masthead Tri-color and anchor light
• Port and starboard navigation lights mounted on bow pulpit.
• D400 wind generator 2011
• Honda 2000 Generator

Electronics/Navigation

• ICOM 735 HAM/SSB radio with ICOM AT150 automatic antenna tuner
• Furuno Navnet Vx2 Cmap radar/chartplotter
• Icom VHF with Ram mic, arch mounted antenna
• Tacktick wind/temp/speed/depth & NEMA display system
• Iridium satellite phone w/ fixed antenna
• Autohelm 3000 autopilot
• XM radio w/ marine antenna
• Aquatic AV USB/IPOD Radio player
• AM/FM radio/tape player with Bose speakers
• Plastimo bulkhead mount view-through compass
• Ritchie compass in navigation station

Safety Equipment

• (6) life jackets
• (3) Kidde class ABC fire extinguishers
• (2) Survival Technologies safety harnesses
• Man overboard life ring and man overboard light
• Gale Rider drogue with new 300' x 5/8" braided line
• Bell
• Flare gun and flares

Miscellaneous

• 10.5 Achilles rib dinghy with Yamaha 15 HP outboard
• 10' Walker Bay rowing and sailing dinghy w/ sail kit

Carisa was sailed for 12 years by her owner/builders in the Gulf of Mexico and the western Caribbean. They sailed her 6 months out of the year from their home in Tallahassee, FL.

 The second owner brought her north to Narraganset Bay, RI. He sailed her there for 6 years and took two trips north to Maine.  He day-sailed and the two summer vacations to Maine.

We have owned Carisa for 9 years, having purchased her in Newport, RI and sailed her down the coast to Florida.  We kept her in Fernandina Beach. FL for 3 years and sailed her to the Bahamas twice a year for 2 months and 3 months. After that we kept her in George Town, Great Exuma, Bahamas for 4 years; sailing her 4 -5 months a year.  That brings us to the present.

The sail plan is wonderful!  There is plenty of sail area and they really power up when the wind blows.  The obvious difference is "no jibs"! Setting the loose-footed mainsails is accomplished with vangs set well outboard to provide good leverage for the full range of the boom.

Carisa easily sails 9-10 knots with wind speeds of 15-16 knots.  With decent sail conditions she will easily make 200+ mile days.  In a flotilla she will out sail every boat except performance catamarans and 65'+ racing mono-hulls.

Most Recent Upgrades and Additions

Sails from Haarstick Sails 2008

Furuno color chart plotter 2008

Achilles 10.5 RIB and 15 hp Yamaha OB 2008

Honda 2000 generator 2008

Air Line Hooka Dive System for 3 divers 2008

Walker Bay 10' rowing and sailing dinghy w/sail kit 2009

Sterling paint on hulls and top sides 2010

Lazy jacks, custom 2010

Atlantic Tower Arch amidships 2011

Tacktick wireless array for wind, depth, temperature, speed and NEMA 2011

Icom VHF M502 and RAM mic 2011

Dyneema netting for all trampolines 2011

Iridium satellite phone and fixed marine antenna 2011

D400 wind generator 2011

Gori 2 blade folding propeller 2012

XM radio and marine antenna 2012

On Demand hot water shower 2014

2 new 4D wet-cell house batteries 2014

Mainsail covers 2014

Mattress covers in forward berth 2014

Lewmar 46 EST electric winch 2014

Main halyards 2015
